Ring Joint Gasket
High temperature and high pressure conditions are common in the oil and gas industry. To sustain under these pressures, and perform well on a long term basis, Sealtech manufactures ring joint gaskets which are resistant and customised. The various styles in which the gaskets are available are:
- R
- Rx
- bx
Ring Material
Various forms of material, shown in the table below, are used for manufacturing Ring Joint Gaskets, which may be manufactured from special material, as per customer's requirement.
| Material (Trade Name) | Ring Identification | DIN Specification | DIN Material No. | AISI ASTM UNS | B.S. | Hardness (max)* | Temprature (0C)* | Specify Density (gr / cm3) | ||
| Brinell HB | Rockwell B | Min. | Max. | |||||||
| Soft iron | D | - | - | - | - | 90 | 56 | -60 | 500 | 7.85 |
| Steel (LCS) | S | - | - | - | - | 120 | 68 | -40 | 500 | 7.85 |
| ASTM A182-F5 | F5 | 12CrMo 195 | 1.7362 | A182-F5 | - | 130 | 72 | -40 | 650 | 7.9 |
| Stainless Steel 304 | S 304 | X5CrNi 1810 | 1.4301 | 304 | 304S15/16/31 | 160 | 83 | -250 | 550 | 7.9 |
| Stainless Steel 304L | S 304L | X2CrNi 1911 | 1.4306 | 304 L | 304S11 | 160 | 83 | -250 | 550 | 7.9 |
| Stainless Steel 309 | S 309 | X15CrNiSi 2012 | 1.4828 | 309 | 309S24 | 160 | 83 | -100 | 1000 | 7.9 |
| Stainless Steel 316 | S 316 | X5CrNiMo 1712 | 1.4401 | 316 | 316S31/33 | 160 | 83 | -100 | 550 | 7.9 |
| Stainless Steel 316L | S 316L | X2CrNiMo 1713 | 1.4404 | 316 L | 316S11/13 | 160 | 83 | -100 | 550 | 7.9 |
| Stainless Steel 316 Ti | S 316 Ti | X10CrNiMoTi 1712 | 1.4571 | 316 Ti | 320S31 | 160 | 83 | -100 | 550 | 7.8 |
| Stainless Steel 321 | S 321 | X6CrNiTi 1810 | 1.4541 | 321 | 321S12/49/87 | 160 | 83 | -250 | 550 | 7.9 |
| Stainless Steel 347 | X347 | X6CrNiNb 1810 | 1.4550 | 347 | 347S31 | 160 | 83 | -250 | 550 | 7.9 |
| Material | Identification | Hardness (Brinell HB) | Hardness (Rockwell B) | Density |
| Inconel | 625 | 180 | 90 | 8.0 |
| Inconel | 825 | 180 | 90 | 8.0 |
| Monel | 400,000 | 180 | 90 | 8.0 |
Pressure Class Rating
| 150 | 3/600 | 900 | 1500 | 2500 | 2000 | 3000 | 5000 | 10000 | |
| R-11 | 1/2 | ||||||||
| R-12 | 1/2 | 1/2 | |||||||
| R-13 | 3/4 | 1/2 | |||||||
| R-14 | 3/4 | 3/4 | |||||||
| R-15 | 1 | ||||||||
| R-16 | 1 | 1 | 1 | 3/4 | |||||
| R-17 | 11/4 | ||||||||
| R-18 | 11/4 | 11/4 | 11/4 | 1 | |||||
| R-19 | 11/2 | ||||||||
| R-20 | 11/2 | 11/2 | 11/2 | 11/2 | 11/2 | 11/2 | |||
| 150 | 3/600 | 900 | 1500 | 2500 | 2000 | 3000 | 5000 | 10000 | |
| R-21 | 11/4 | ||||||||
| R-22 | 2 | ||||||||
| R-23 | 2 | 11/2 | 2 | ||||||
| R-24 | 2 | 2 | 2 | 2 | |||||
| R-25 | 21/2 | ||||||||
| R-26 | 21/2 | 2 | 21/2 | ||||||
| R-27 | 21/2 | 21/2 | 21/2 | 21/2 | |||||
| R-28 | 21/2 | ||||||||
| R-29 | 3 | ||||||||
| R-30 | 3 | ||||||||
| 150 | 3/600 | 900 | 1500 | 2500 | 2000 | 3000 | 5000 | 10000 | |
| R-31 | 3 | 3 | 3 | 3 | |||||
| R-32 | 3 | ||||||||
| R-33 | 31/2 | ||||||||
| R-34 | 31/2 | ||||||||
| R-35 | 3 | 3 | |||||||
| R-36 | 4 | ||||||||
| R-37 | 4 | 4 | 4 | 4 | |||||
| R-38 | 4 | ||||||||
| R-39 | 4 | 4 | |||||||
| R-40 | 5 | ||||||||
| 150 | 3/600 | 900 | 1500 | 2500 | 2000 | 3000 | 5000 | 10000 | |
| R-41 | 5 | 5 | 5 | 5 | |||||
| R-42 | 5 | ||||||||
| R-43 | 6 | ||||||||
| R-44 | 5 | 5 | |||||||
| R-45 | 6 | 6 | 6 | 6 | |||||
| R-46 | 6 | 6 | |||||||
| R-47 | 6 | ||||||||
| R-48 | 8 | ||||||||
| R-49 | 8 | 8 | 8 | 8 | |||||
| R-50 | 8 | 8 | |||||||
| 150 | 3/600 | 900 | 1500 | 2500 | 2000 | 3000 | 5000 | 10000 | |
| R-51 | 8 | ||||||||
| R-52 | 10 | ||||||||
| R-53 | 10 | 10 | 10 | 10 | |||||
| R-54 | 10 | 10 | |||||||
| R-55 | 10 | ||||||||
| R-56 | 12 | ||||||||
| R-57 | 12 | 12 | 12 | 12 | |||||
| R-58 | 12 | ||||||||
| R-59 | 14 | ||||||||
| R-60 | 12 | ||||||||
| 150 | 3/600 | 900 | 1500 | 2500 | 2000 | 3000 | 5000 | 10000 | |
| R-61 | 14 | ||||||||
| R-62 | 14 | ||||||||
| R-63 | 14 | ||||||||
| R-64 | 16 | ||||||||
| R-65 | 16 | 16 | |||||||
| R-66 | 16 | 16 | |||||||
| R-67 | 16 | ||||||||
| R-68 | 18 | ||||||||
| R-69 | 18 | 18 | |||||||
| R-70 | 18 | 18 | |||||||
| 150 | 3/600 | 900 | 1500 | 2500 | 2000 | 3000 | 5000 | 10000 | |
| R-71 | 18 | ||||||||
| R-72 | 20 | ||||||||
| R-73 | 20 | 20 | |||||||
| R-74 | 20 | 20 | |||||||
| R-75 | 20 | ||||||||
| R-76 | 24 | ||||||||
| R-77 | 24 | ||||||||
| R-78 | 24 | ||||||||
| R-79 | 24 | ||||||||
| R-80 | 22 | ||||||||
| 150 | 3/600 | 900 | 1500 | 2500 | 2000 | 3000 | 5000 | 10000 | |
| R-81 | 22 | ||||||||
| R-82 | 1 | ||||||||
| R-83 | |||||||||
| R-84 | 1½ | ||||||||
| R-85 | 2 | ||||||||
| R-86 | 2½ | ||||||||
| R-87 | 3 | ||||||||
| R-88 | 4 | ||||||||
| R-89 | 3½ | ||||||||
| R-90 | 5 | ||||||||
| 150 | 3/600 | 900 | 1500 | 2500 | 2000 | 3000 | 5000 | 10000 | |
| R-91 | 10 | ||||||||
| R-92 | |||||||||
| R-93 | 26 | ||||||||
| R-94 | 28 | ||||||||
| R-95 | 30 | ||||||||
| R-96 | 32 | ||||||||
| R-97 | 34 | ||||||||
| R-98 | 36 | ||||||||
| R-99 | |||||||||
| R-100 | 26 | ||||||||
| 150 | 3/600 | 900 | 1500 | 2500 | 2000 | 3000 | 5000 | 10000 | |
| R-101 | 28 | ||||||||
| R-102 | 30 | ||||||||
| R-103 | 32 | ||||||||
| R-104 | 34 | ||||||||
| R-105 | 36 |
